BOMAG BM500/15 Cold Planer

BOMAG BM500/15 Cold Planer

The BM500/15’s new innovative design features systems that monitor and respond to optimum output levels for lower fuel consumption and versatile milling speeds with higher cutting power that increase productivity.

Less Manual Refinishing

The side plate can be set straight, with no material accumulation during operation. This produces equally high stability on both sides.

Maximum Versatility & Production

BOMAG quick-change milling drums are available in different working widths. The optimum line spacing and best cutting speed for the job can be selected to reduce running production costs.

Easy Maintenance

The operator has quick access through an easy-to-open engine hood, revealing the entire service area and which simultaneously acts also as a protective roof.

Fatigue-Free & Safe Operation

An attractive and safe operating environment which provides ideal conditions for work in a seated position – with no harmful vibration.

ADDING VALUE TO YOUR BUSINESS

Customer Support Agreements – Genuine, High Quality Parts – Dedicated Product Support Representatives

Being a Power Equipment Company customer means having a complete set of services at your fingertips. Our promise is that we will be your loyal and long-standing partner, delivering the right solutions and support to power your business. We are committed to increasing the positive return on your investment and maximizing uptime.

Check out our used inventory

Main Specs

  • Operating Weight 16755LBS
  • Horsepower 125HP
  • Emission Rating Tier 4i
  • Milling Width 19.7 in

Engine

  • Engine Make/Model Deutz / TCD 2012
  • Net Torque 384LBF/FT
  • Rated Speed 2100rpm
  • Displacement 244in3

Drivetrain

  • Transmission Type Mechanical
  • Max Forward Speed 3.7mph
  • Drive Configuration 3 or 4 solid rubber wheels
  • Wheel Sizes (Front / Rear) 22.1in x 8in / 22.1in x 10in
  • Working Speed 32.8 yds/min
  • Fuel Consumption @ Rated Power 0.35 lb/hph

Performance

Dimensions

  • Operating Length - Conveyor Extended 28ft 1in
  • Transport Length - Conveyor Folded 28ft 1in
  • Max Width 5ft 4in
  • Transport Width 5ft 4in
  • Max Conveyor Clearance Height 12ft 8in
  • Transport Height - Conveyor Folded 9ft

Performance

  • Cutting Radius - Rhs 9.6in
  • Cutting Diameter 27.6in
  • Number of Cutting Teeth 58
  • Milling Width 19.7in
  • Milling Depth 8.3in
  • Rotor Line Spacing 0.59in
  • Max Rotor Speed 145 rpm

Conveyor System

  • Length 20ft 6in
  • Width 15.7in
  • Conveyor Swing 20° Left / 25° Right

Fluid Capacities

  • Fuel Tank 60.8 gal
  • Hydraulic Tank 26.4 gal
  • Water Tank 158.5 gal
