BOMAG BPR 70/70 D Reversible Vibratory Plates

BOMAG BPR 70/70 D Reversible Vibratory Plates

BOMAG offers a range of reversible vibratory plates that are popular choices on many small and medium-sized construction sites. These are uncompromising compaction units for earthworks, asphalt and block paving.

BOMAG ECONOMIZER

The BOMAG ECONOMIZER shows the operator realtime compaction progress on a continuous easy-read display. This support system prevents unnecessary passes and immediately identifies weak spots.

Highly Mobile

Robust, solid rubber transport wheels are quick-mounting, allowing easy movement to the next site.

Fully Protected

The hinged, all-round protection hood provides maximum protection and optimum access to the engine and other components, saving time and money.

Individually Adapted

Every operator can select the ideal working position with the height adjustable, low-vibration steering rod.

ADDING VALUE TO YOUR BUSINESS

Customer Support Agreements – Genuine, High Quality Parts – Dedicated Product Support Representatives

Being a Power Equipment Company customer means having a complete set of services at your fingertips. Our promise is that we will be your loyal and long-standing partner, delivering the right solutions and support to power your business. We are committed to increasing the positive return on your investment and maximizing uptime.

Check out our used inventory

Main Specs

  • Operating Weight 1226LBS
  • Horsepower 12.5HP
  • Working Speed 92 ft/min
  • Compaction Width 33.5 in

Engine

  • Engine Make/Model Hatz / 1D81
  • Net Torque 26.7LBF/FT
  • Rated Speed 2700rpm
  • Displacement 40.7in3

Drivetrain

  • Cooling Method Air
  • Number of Cylinders 1
  • Fuel Type Diesel
  • Fuel Tank Capacity 2.6 gal

Performance

Dimensions

  • Machine Length 3ft 2in
  • Length w/ Steering Rod 6ft 1in
  • Widths (3 extension modes) 21.7in - 27.6in - 33.5in
  • Height 2ft 10in

Vibratory System

  • Frequency 4,020 vpm
  • Centrifugal Force 15,736 lbf
  • Max Gradeability 35%

Optional Equipment

  • BOMAG Economizer
  • Extension Plates
  • Service Kit
  • Vulcolan Mat
