BOMAG BW 145 D-5 Single Drum Vibratory Roller

BOMAG BW 145 D-5 Single Drum Vibratory Roller

The compact dimensions and dependable compaction performance of the BW 124 PDH-40 make it the ideal choice for site preparation, landscaping, and trench compaction.

Compaction Power

The BW 124 PDH-40 has one frequency and amplitude setting that are perfectly matched to the static linear load for reliable compaction results.

Excellent Traction

Outstanding all-terrain performance, with a maximum gradeability of 55%.

More Production & Uptime

Reduced running costs due to low fuel consumption and short on-site servicing times.

Safety & Comfort

All-around visibility and ROPS/FOPS provide optimum operator protection.

ADDING VALUE TO YOUR BUSINESS

Customer Support Agreements – Genuine, High Quality Parts – Dedicated Product Support Representatives

Being a Power Equipment Company customer means having a complete set of services at your fingertips. Our promise is that we will be your loyal and long-standing partner, delivering the right solutions and support to power your business. We are committed to increasing the positive return on your investment and maximizing uptime.

Check out our used inventory

Main Specs

  • Operating Weight 10472LBS
  • Horsepower 74HP
  • Emission Rating Tier 4 Final
  • Roller Width 56.1 in

Engine

  • Engine Make/Model Deutz / TD 2.9 L04
  • Net Torque 192LBF/FT
  • Rated Speed 2400rpm
  • Displacement 177in3

Drivetrain

  • Transmission Type Hydrostatic
  • Max Forward Speed 6.2mph
  • Tire Size 12.5 -20
  • Number of Tires 2
  • Tire Type 12PR
  • Fuel Tank Capacity 29 gal

Performance

Dimensions

  • Length 14ft 4in
  • Width 5ft 1in
  • Height - ROPS / No ROPS 8ft 11in / 5ft 2in
  • Wheelbase 7ft 4in
  • Overhang - Left / Right 2.6in / 2.6in
  • Ground Clearance 12.6in

Drum Dimensions

  • Width 56.1in
  • Diameter 41.7in
  • Drum Shell Thickness 0.79in
  • Linear Drum Load 93.9 lbs/in

Steering

  • Steering Axle Articulation
  • Steering Angle 35°
  • Oscillation Angle 12°
  • Turning Radius - Inside 9ft 5in

Vibratory System

  • Vibratory Frequency (stage I / stage II) 1,860 vpm / 2,280 vpm
  • Amplitude (stage I / stage II) 0.067in / 0.031in
  • Centrifugal Force (stage I / stage II) 17,985 lbf / 12,589 lbs
  • Gradeability 48% (w/ vibration) / 51% (w/o vibration)
