BOMAG BW 177 D-5 Single Drum Vibratory Roller

BOMAG BW 177 D-5 Single Drum Vibratory Roller

An innovative new design for production, quality, and return-on-investment, the BW 177-5 Series single drum vibratory rollers are ideal for confined job sites, municipality projects, and all road construction/maintenance applications.

The BW 177-5 Series rollers include optional cab, leveling blade, and padfoot shell kits increase machine versatility.

Compaction Power

The BW 177-5 Series rollers are Tier 4 Final compliant and utilize a diesel oxidation catalyst (DOC).

Excellent Traction

Outstanding all-terrain performance, with a maximum gradeability of 46% in vibration modes.

More Production & Uptime

Owners will achieve efficient utilization, uptime, and return on their equipment investment.

Safety & Comfort

Operators will appreciate the updated cockpit with its spacious area, easy reach controls, and safe sight lines.

ADDING VALUE TO YOUR BUSINESS

Customer Support Agreements – Genuine, High Quality Parts – Dedicated Product Support Representatives

Being a Power Equipment Company customer means having a complete set of services at your fingertips. Our promise is that we will be your loyal and long-standing partner, delivering the right solutions and support to power your business. We are committed to increasing the positive return on your investment and maximizing uptime.

Check out our used inventory

Main Specs

  • Operating Weight 14132LBS
  • Horsepower 74HP
  • Emission Rating Tier 4 Final
  • Roller Width 66.4 in

Engine

  • Engine Make/Model Deutz / TD 2.9 L04
  • Net Torque 192LBF/FT
  • Rated Speed 2400rpm
  • Displacement 177in3

Drivetrain

  • Transmission Type Hydrostatic
  • Max Forward Speed 6.5mph
  • Tire Size 14.9 - 24
  • Number of Tires 2
  • Tire Type 8PR
  • Fuel Tank Capacity 29 gal

Performance

Dimensions

  • Length 14ft 10in
  • Width 5ft 11in
  • Height - ROPS / No ROPS 9ft 2in / 5ft 5in
  • Wheelbase 7ft 8in
  • Overhang - Left / Right 2.6in / 2.6in
  • Ground Clearance 15in

Drum Dimensions

  • Width 66.4in
  • Diameter 48.4in
  • Drum Shell Thickness 0.79in
  • Linear Drum Load 129.5 lbs/in

Steering

  • Steering Axle Articulation
  • Steering Angle 35°
  • Oscillation Angle 12°
  • Turning Radius - Inside 9ft 9in

Vibratory System

  • Vibratory Frequency (stage I / stage II) 1,860 vpm / 2,280 vpm
  • Amplitude (stage I / stage II) 0.075in / 0.031in
  • Centrifugal Force (stage I / stage II) 25,179 lbf / 16,636 lbs
  • Gradeability 46% (w/ vibration) / 49% (w/o vibration)
