Komptech Cribus 2800 E Trommel Screen

Komptech Cribus 2800 E Trommel Screen

With the largest screening surface for its overall length, the Cribus 2800 E sets the standard in the compact class. Everything on the Cribus E is driven electrically, from the hopper to the discharge belts.

More Productivity Per Foot

Despite being only 35 feet long, the Cribus 2800 E boasts a screening area of 301 ft².

Clean Discharge

The new maintenance-free friction wheel drive with the patented WHEELGRIP anti-slip technology gives maximum efficiency with minimum wear cost.

Quick Drum Change

The operator needs only to move the hopper forward, press a button to raise the drum, and then remove it with a loader.

Adjustable Conveyors

For users who want to stay flexible, an option is available that lets them switch the discharge side on-site.

ADDING VALUE TO YOUR BUSINESS

Customer Support Agreements – Genuine, High Quality Parts – Dedicated Product Support Representatives

Being a Power Equipment Company customer means having a complete set of services at your fingertips. Our promise is that we will be your loyal and long-standing partner, delivering the right solutions and support to power your business. We are committed to increasing the positive return on your investment and maximizing uptime.

Click here to view our used inventory of Screeners.

Main Specs

  • Operating Weight 16 tons
  • Electrical Power Input 25 kW
  • Screening Area 301 ft²
  • Throughput 220 yd³/hr

Engine

  • Diesel Generator Output 47.6 kW

Drivetrain

Performance

Dimensions

  • Length 34ft 9in (transport) / 43ft (working)
  • Width 8ft 4in (transport) / 16ft 5in (working)
  • Height 13ft 1in (transport) / 13ft 1in (working)
  • Conveyor Angle (side/rear) 30° / 30°

Feed Hopper

  • Hopper Volume 6.5 yd³
  • Filling Length 13ft 1in
  • Filling Width 5ft 6in
  • Filling Height 9ft 8in

Screening Drum

  • Diameter 7ft 3in
  • Length 15ft 1in
  • Drum Speed 20 RPM

Material Discharge

  • Max Height (coarse fraction) 8ft (option 11ft 6in)
  • Max Height (fine fraction) 7ft 5in (option 11ft)

Optional Equipment

  • Diesel generator
  • Cleanfix fan
  • Magnet drum
  • Adjustable belt speed
  • Scraper for round brush
  • Central lubrication
  • Hopper pre-screening
  • Hopper sensor control
  • Remote control
  • Feed device
