Liebherr L 550 Wheel Loader

Liebherr L 550 Wheel Loader

The Liebherr L 550 Wheel Loader makes a reliable contribution to commercial success. The low fuel consumption of the Liebherr L 550 wheel loader reduces operating costs and increases productivity with high handling capacity.

Liebherr Power Efficiency (LPE)

The Liebherr L 550 Wheel Loader driveline with Liebherr Power Efficiency (LPE) reduces wheel loader fuel consumption by 25% or more when compared to conventional travel gears.

Optimal Performance

The Liebherr L 550 wheel loader driveline allows for optimal positioning of the diesel engine. In this wheel loader class the diesel engine is rotated 90° and mounted transverse to the direction of travel.

Reliability

All the materials used in the Liebherr wheel loaders have passed extensive tests to ensure that they meet Liebherr’s exacting standards even in the toughest conditions. The advanced concept and proven quality make Liebherr wheel loaders the benchmark of reliability.

Extraordinary Comfort

The operator’s cab has been designed to ensure maximum comfort, enhance productivity, and ergonomics. Tool controls and displays are strategically arranged for ease of operation. The newly developed mounting system substantially reduces noise and vibration in the cab‘s interior.

ADDING VALUE TO YOUR BUSINESS

Customer Support Agreements – Genuine, High Quality Parts – Dedicated Product Support Representatives

Being a Power Equipment Company customer means having a complete set of services at your fingertips. Our promise is that we will be your loyal and long-standing partner, delivering the right solutions and support to power your business. We are committed to increasing the positive return on your investment and maximizing uptime.

Click here to view our used inventory of Wheel Loaders.

Main Specs

  • Bucket Capacity 4.2YD3
    Compatible Range
  • Operating Weight 38140LBS
  • Horsepower 173HP
  • Emission Rating Interim T4

Engine

  • Engine Make/Model Liebherr / D934 A7
  • Net Torque 622LBF/FT
  • Displacement 428in3
  • Rated Speed 1,500 rpm

Drivetrain

  • Transmission Type Hydrostatic
  • Controls Actuation Electronic
  • Differential Lock-Front/Rear Front: LSD / Rear: LSD
  • Tire Size 23.5 R25
  • Max Forward Speed 24.9 mph
  • Max Reverse Speed 24.9 mph

Performance

  • Linkage Geometry Z-bar (industrial lift arm available)
  • Straight Tipping Load 30,390 lbs
  • Full Turn Tipping Load 26,785 lbs
  • Shovel Breakout Force 31,475 lbf
  • Max Hinge Pin Height 12ft 10in
  • Steering Articulation Angle 40°

Dimensions

  • Width Over Tires 8ft 10in
  • Height To Top Of Cab 11ft
  • Ground Clearance 19in
  • Chassis Type Articulated
  • Full Lift Dump Height 9ft 5in
  • Full Lift Reach Height (STD bucket) 4ft
  • Length (including STD shovel) 27ft 2in
  • Wheelbase 10ft 10in
  • ROPS / FOPS Yes / Yes
  • ROPS / FOPS Ratings ISO 3471 / ISO 3449

Hydraulics

  • Hydraulic Pump Type Axial Piston Pump
  • Hydraulic Fluid (tank/system) 35.7 gal / 64.7 gal
  • Pump Flow 62 gal/min
  • Pump Flow - Steering 62 gal/min
  • Loader Control Servo Joystick
  • Relief Pressure 4,786 PSI
  • Cycle Time - Raise 5.5 sec
  • Cycle Time - Lower 2.7 sec
  • Cycle Time - Dump 2.3 sec
  • Cycle Time - Total 10.5 sec
