Takeuchi TB240 Compact Excavator

Takeuchi TB240 Compact Excavator

The Takeuchi TB240 Compact Excavator provides exceptional power, performance, a wide working range, and an excellent feature set. The cabin is spacious and well appointed ensuring operator comfort and efficiency.

Power and Performance

The Tier 4 Final Yanmar engine delivers exceptional power and performance and features a DOC and DPF exhaust after-treatment system for reduced emissions.

Wrap Around Counterweight

Protects key engine and hydraulic components from damage while delivering excellent stability.

Multi-Informational Display

Display is easy to read in all lighting conditions and keeps the operator informed on the status of the machine.

Serviceability

The service access hood eliminates the tilt-up cabin, and provides outstanding access to the control valve, hydraulic lines, hydraulic tank, and pattern change valve.

ADDING VALUE TO YOUR BUSINESS

Customer Support Agreements – Genuine, High Quality Parts – Service Network

Being a Power Equipment Company customer means having a complete set of services at your fingertips. We can offer you a long-term partnership, protect your revenue and provide a full range of customer solutions using high quality parts, delivered by passionate people. We are committed to increasing the positive return on your investment and maximizing uptime.

Click here to view our used inventory of Excavators.

Main Specs

  • Bucket Capacity 0.14YD3
    Compatible Range
  • Operating Weight 8990LBS
  • Horsepower 35.8HP
  • Emission Rating Tier 4 Final

Engine

  • Engine Make/Model Yanmar / 4TNV88C
  • Net Torque 102.6LBF/FT
  • Rated Speed 1430rpm
  • Displacement 133.6in3

Drivetrain

  • Transmission Type Hydrostatic
  • Max Forward Speed 3mph
  • Track Shoe Width 13.8in
  • Track Shoe Type Rubber

Performance

  • Boom Length 5ft 3in
  • Max Dig Depth 11ft 4.4in
  • Dump Height 12ft 6.7in
  • Max Digging Reach 18ft 2.3in
  • Boom Tearout Force 4,114 lbf
  • Bucket Breakout Force 9,959 lbf
  • Max Hydraulic Pump Flow 30.6 gal/min
  • Auxiliary Hydraulic Flow 17.1 gal/min
  • Ground Bearing Pressure 4.6 PSI

Dimensions

  • Transport Length 16ft 8.2in
  • Transport Height 8ft 2.6in
  • Transport Width 5ft 8.5in
  • Tailswing Radius 4ft 5.7in
  • Ground Clearance 11.6in
  • Hydraulic System Capacity 9.2 gal
