Takeuchi TB260 Compact Excavator

Takeuchi TB260 Compact Excavator

The Takeuchi TB260 Compact Excavator has exceptional power, performance, a wide working range, and impressive feature set. The cabin is spacious and well appointed ensuring operator comfort and efficiency.

Powerful Dig Forces

The Takeuchi TB260 Compact Excavator excellent arm and bucket power provide the perfect combination of power, speed, and versatility at your fingertips.

Heavy Duty Blade

Integrated gusset reinforcements and large blade cylinder give you the strength and durability you expect from the class leader.

Large Travel Pedals

Fully support the operator’s feet for greater comfort and control while traveling. Additionally, pedals are raised off floor to reduce build-up of dirt and debris that can limit or impede travel functions.

Serviceability

The side by side radiator and hydraulic oil cooler features increased cooling capacity and are easy to inspect, clean and maintain.

ADDING VALUE TO YOUR BUSINESS

Customer Support Agreements – Genuine, High Quality Parts – Service Network

Being a Power Equipment Company customer means having a complete set of services at your fingertips. We can offer you a long-term partnership, protect your revenue and provide a full range of customer solutions using high quality parts, delivered by passionate people. We are committed to increasing the positive return on your investment and maximizing uptime.

Click here to view our used inventory of Excavators.

Main Specs

  • Bucket Capacity 0.28YD3
    Compatible Range
  • Operating Weight 12645LBS
  • Horsepower 47.6HP
  • Emission Rating Tier 4 Final

Engine

  • Engine Make/Model Yanmar / 4TNV86CT
  • Net Torque 130.5LBF/FT
  • Rated Speed 1560rpm
  • Displacement 127.6in3

Drivetrain

  • Transmission Type Hydrostatic
  • Max Forward Speed 3mph
  • Track Shoe Width 15.7in
  • Track Shoe Type Rubber

Performance

  • Boom Length 5ft 10in
  • Max Dig Depth 12ft 9in
  • Dump Height 19ft 5in
  • Max Digging Reach 20ft 6in
  • Boom Tearout Force 5,755 lbf
  • Bucket Breakout Force 12,756 lbf
  • Max Hydraulic Pump Flow 45.3 gal/min
  • Auxiliary Hydraulic Flow 27 gal/min
  • Ground Bearing Pressure 4.6 PSI

Dimensions

  • Transport Length 18ft 8.2in
  • Transport Height 8ft 5.4in
  • Transport Width 6ft 6.7in
  • Tailswing Radius 4ft 3.1in
  • Ground Clearance 13.1in
  • Hydraulic System Capacity 23.8 gal
