Takeuchi TL6R Compact Track Loader

Takeuchi TL6R Compact Track Loader

The Takeuchi TL6R Compact Track Loader is a radial lift loader designed to excel on job sites that may have height and width restrictions.

Powerful Drives

Double reduction planetary drives provide exceptional pushing power, delivering maneuverability, outstanding performance, and the standard two speed travel allows for increased travel speeds.

Built to Last

The heavy duty rear door is built to protect the radiator and hydraulic oil cooler from rear impacts, and will provide years of service and dependability.

Pilot Joystick Controls

Respond immediately to operator input for greater control and performance, and they are low effort for excellent comfort.

Serviceability

With a tilt back operator’s station and large removable belly pans routine maintenance and cleaning is easy to perform.

ADDING VALUE TO YOUR BUSINESS

Customer Support Agreements – Genuine, High Quality Parts – Dedicated Product Support Representatives

Being a Power Equipment Company customer means having a complete set of services at your fingertips. Our promise is that we will be your loyal and long-standing partner, delivering the right solutions and support to power your business. We are committed to increasing the positive return on your investment and maximizing uptime.

Click here to view our used inventory of Skid Steer Loaders

Main Specs

  • Bucket Capacity 0.65YD3
    Compatible Range
  • Operating Weight 7780LBS
  • Horsepower 65.2HP
  • Emission Rating Tier 4 Final

Engine

  • Engine Make/Model Kubota / V2403-CR-TE4B
  • Net Torque 144.3LBF/FT
  • Rated Speed 1500rpm
  • Displacement 148.5in3
  • Cylinders 4
  • Fuel Tank Capacity 20.1 gal

Drivetrain

  • Transmission Type Hydrostatic
  • Controls Actuation Pilot joystick
  • Max Forward Speed 6mph
  • After Treatment System Diesel Particulate Filter
  • Undercarriage Type Hi Mount Drive Motor
  • Drive Method Sprocket

Performance

  • Linkage Geometry Radial
  • Straight Tipping Load 5,269 lbs
  • Rated Operating Capacity 1,841 lbs
  • Bucket Breakout Force 5,930 lbs
  • Lift Arm Breakout Force 4,860 lbs
  • Traction Force 8,655 lbs
  • Hydraulic Power 30.7 hp
  • Pump Flow 17.8 gal/min

Dimensions

  • Transport Height 6ft 5.8in
  • Transport Length 10ft 11.1in
  • Width (no bucket) 5ft 0.2in
  • Max Lift Height to Bucket Pin 9ft 6.4in
  • Dump Height Fully Raised 7ft 5.6in
  • Max Dump Angle 38°
  • Dump Reach Fully Raised 1ft 10in
  • Max Bucket Rollback @ Ground 31°
  • Ground Clearance 9.1in

Undercarriage

  • Track Rollers 4
  • Track Shoe Width 12.6in
