Takeuchi TW40 Compact Wheel Loader

Takeuchi TW40 Compact Wheel Loader

Compact and agile the Takeuchi TW40 Compact Wheel Loader is able to work in areas with limited accessibility and space.  The hydraulic skid steer style attachment coupler allows for quick and easy attachment exchanges and it is ideal for landscaping, general contracting, agricultural, and snow removal applications.

Complete Functionality

The multi-function joystick allows the operator to control all loader, directional, and travel speed functions with one controller.

Strong and Durable

The outboard planetary drives allow for larger bearings to be utilized and house oil separately from the differentials.  This keeps the oil cleaner and reduces heat extending component life and durability.

Comfort and Convenience

The operator’s cabin on the TW40 is spacious, well appointed, features a deluxe suspension seat, and an adjustable arm rest.

Serviceability

Mounted under the engine hood the hydraulic tank and sight gauge are well protected and easy to access.

ADDING VALUE TO YOUR BUSINESS

Customer Support Agreements – Genuine OEM Parts – Service Network

Being a Power Equipment Company customer means having a complete set of services at your fingertips. Our promise is that we will be your loyal and long-standing partner, delivering the right solutions and support to power your business. We are committed to increasing the positive return on your investment and maximizing uptime.

Click here to view our used inventory of Wheel Loaders.

Main Specs

  • Bucket Capacity 0.66YD3
  • Operating Weight 7275LBS
  • Horsepower 39.4HP
  • Emission Rating Interim T4

Engine

  • Engine Make/Model Perkins / 403D-15T
  • Net Torque 82.6LBF/FT
  • Rated Speed 1800rpm
  • Displacement 91in3
  • Cylinders 3
  • Fuel Tank Capacity 18.5 gal

Drivetrain

  • Transmission Type Hydrostatic
  • Controls Actuation Electronic
  • Max Forward Speed 12.4mph
  • Differential Lock-Front/Rear Front: Limited Slip / Rear: Open
  • Tire Size 15.5 - 16.5

Performance

  • Linkage Geometry Z-Bar
  • Straight Tipping Load 3,858 lbs
  • Full Turn Tipping Load 3,417 lbs
  • Rated Operating Capacity 1,708 lbs
  • Bucket Breakout Force 4,878 lbs
  • Lift Arm Breakout Force 4,181 lbs
  • Traction Force 5,620 lbs
  • Cycle Times Raised Full Load: 4s / Lower No Load: 3.5s / Dump Full Load: 1s

Dimensions

  • Operating Height 11ft 11in
  • Max Lift Height to Bucket Pin 9ft 6.5in
  • Bucket Clearance Height 9ft
  • Dump Height 7ft 0.6in
  • Max Dump Angle 34°
  • Max Reach Raised 2ft 8.2in
  • Max Bucket Rollback @ Ground 51°
