Volvo EC250E

Main Specs

• Engine Output - Gross 225 hp (168 kW)

Engine

Drivetrain

Performance

Dimensions

Description

• Operating Weight 60460 lbs (27420 kg)
• Standard Arm Length 9 ft 9 in (2970 mm)

Telematics

• Telematics Available Yes

Driveline

• Engine Manufacturer Volvo
• Engine Model D8M
• Displacement 470 Inches³ (7.7 ltr)
• Rated Speed 1600 rpm
• Engine Output - Net 224 hp (167 kW)
• Engine Output - Gross 225 hp (168 kW)
• Number Of Track Rollers - Each Side 9
• Track Shoe Width 32 inches (800 mm)

Dimensions

• Bucket Capacity 0.73-2.3 yd³ (0.56-1.76 m³)
• Bucket Weight 1763-3163 lbs (800-1435 kg)
• Transport Length Mono Boom 33 ft 7 in (10230 mm)
• Max Transport Height 11 ft 6 in (3515 mm)
• Max Machine Width 11 ft 1 in (3390 mm)
• Track Length On Ground 12 ft 8 in (3850 mm)
• Zero Tailswing No
• Heaped Bucket Capacity 1.49 yd³ (1.14 m³)
• Variable Undercarriage Availability No
• Ground Level Reach 33 ft 4 in (10160 mm)
• Dig Height 31 ft 9 in (9685 mm)
• Dump Height - Mono Boom 22 ft (6710 mm)
• Dig Depth 23 ft 2 in (7060 mm)

Capacities

• Fuel Tank 124.7 gallons (US) (472 ltr)

Performance

• Ground Bearing Pressure 5.9 PSI (40.6 kPa)
• Arm Tearout 28740 lbf (128 kN)
• Bucket Breakout 40710 lbf (181 kN)
• Number Of Main Pumps 2
• Main Pump - Flow 126.8 gallons (US) / min (480 lt/min)
