BOMAG BW 90 AD-5 Tandem Ride On Roller

BOMAG BW 90 AD-5 Tandem Ride On Roller

BOMAG compact tandem vibratory rollers are perfectly designed for walkways and repair work, as well as finishing work in road construction. BOMAG compact tandem rollers have also acquired an excellent reputation in gardening and landscaping.

Ease of Use Is Standard

Every function is self-explanatory and intuitive to operate after a very short time. The main functions can be selected precisely and error-free by the ergonomic control lever.

Clean Edges

The edge cutting unit can be equipped with various tools for cutting and pressing, and operated with the control lever.

BOMAG ECONOMIZER

The patented BOMAG ECONOMIZER shows the operator the current degree of compaction at all times. LED’s provide permanent information and effectively prevent under or over-compaction.

Comfortable Compaction Work

In tandem with the IVC (Intelligent Vibration Control) system, the exciter system guarantees consistent compaction and reliable operation at all times.

ADDING VALUE TO YOUR BUSINESS

Customer Support Agreements – Genuine, High Quality Parts – Dedicated Product Support Representatives

Being a Power Equipment Company customer means having a complete set of services at your fingertips. Our promise is that we will be your loyal and long-standing partner, delivering the right solutions and support to power your business. We are committed to increasing the positive return on your investment and maximizing uptime.

Check out our used inventory

Main Specs

  • Operating Weight 3527LBS
  • Horsepower 20HP
  • Emission Rating Tier 4 Final
  • Roller Width 35.4 in

Engine

  • Engine Make/Model Kubota / D902
  • Net Torque 40LBF/FT
  • Rated Speed 3200rpm
  • Displacement 54in3

Drivetrain

  • Transmission Type Hydrostatic
  • Max Forward Speed 6.2mph
  • Cooling Method Water
  • Brake Type Service: Hydrostatic / Parking: Hydro-mechanical
  • Fuel Tank Capacity 7.9 gal

Performance

Dimensions

  • Length 7ft 2in
  • Width 3ft 1in
  • Height - ROPS / No ROPS 7ft 6in / 5ft 4in
  • Wheelbase 4ft 10in
  • Overhang - Left / Right 1.1in / 1.1in
  • Ground Clearance 10in

Drum Dimensions

  • Width (front/rear) 35.4in / 35.4in
  • Diameter (front/rear) 22.8in / 22.8in
  • Drum Shell Thickness 0.4in
  • Linear Drum Load (front/rear) 49.8 lbs/in / 49.8 lbs/in
  • Water Tank Capacity 26.4 gal

Vibratory System

  • Vibratory Frequency (front/rear) 3,780 vpm / 3,780 vpm
  • Amplitude (front/rear) 0.02in / 0.02in
  • Centrifugal Force (front/rear) 3,822 lbf / 3,822 lbf
  • Gradeability 30% (w/ vibration) / 40% (w/o vibration)

Steering

  • Steering Axle Articulation
  • Steering Angle 33°
  • Oscillation Angle
  • Turning Radius - Inside 6ft 7in
